Security Roller Grilles - Knightguard™ Security Roller Grilles

FREE Measure & Quote

Knightguard Security roller grilles are an ideal solution where strong security is required that provides a physical barrier while allowing unrestricted airflow, light transmission and high visibility through the roller grille.

Knightguard Security roller grilles are suitable for a wide variety of applications in commercial shop fronts, hospitality industry, retail industry and even homes & residential dwellings. They're ideal for maximising limited space - by rolling up and out of the way they provide an unobstructed passage way when open.

The Knightguard Security roller grille is high in performance. The interconnecting aluminium links which make up the Knightguard Security roller grille curtain offer high strength, toughness and great looks.

The compact roll size means Knightguard Security roller grille will take up less space and be suitable for smaller openings or restricted head room than comparable roller grille products.

Knightguard Security roller grille roller shutters are easy to use and operate with both manual and a variety of electric control options available.

Advanced Shutter Industries has been a manufacturer of roller shutters and roller grilles since 1976 and continues to offer some of the best products available in Australia today.

Knightguard commercial roller shutters and roller grilles are manufactured in our Belmore factory in Sydney NSW Australia for supply & installation and are available to be supplied to city & country areas in Brisbane QLD, Melbourne VIC, Hobart TAS, Adelaide SA, Perth WA, Darwin NT, Canberra ACT, and are also available for export outside of Australia.

Book your FREE quote today.

FOR FREE EXPERT ADVICE
Ring us on (02) 9718 9988 today!

Who is better placed to advise you on your roller shutter project than the manufacturer?
We have been manufacturing roller shutters since 1976.

For no-obligation expert advice for your application, give us a ring or email us.

Benefits of Knightguard™ Security Roller Grilles


Protect your business from unwanted intruders

  • Knightguard Security roller grilles increase the security of your business and are a visible deterrent to would-be intruders.

Protection with ventilation

  • Knightguard Security roller grilles provide protection while allowing unrestricted ventilation through the roller grille even when closed.

Protection with visibility

  • Knightguard Security roller grilles provide protection with full visibility through the roller shutter even when closed.

Uses


Knightguard Security roller grilles are the perfect solution for a range of commercial shop front and residential applications. The possibilities for use are endless. Here are just a few examples:

  • Shopping centres, shopping complexes, shop fronts & shop windows (e.g. retail industry)
  • Service counters, servery areas, food & drink counters, kiosks (e.g. bars, pubs, hotels, commercial kitchens, cafes, restaurants & other categories in the hospitality industry)
  • Carports, garage roller doors, storage areas

Controls and Operation


Knightguard Security roller grilles are simple to use and operate with a variety of manual and electric motor controlled lifting mechanisms available, giving you full control over your environment. Operation, opening and closing, locking and unlocking is customised to your needs so you choose how and where you want to open and close your Knightguard Security roller grille, whether it is from the inside, outside, both inside and outside, via keylock, hasp and staple, electric key lock or radio remote control.


Electric Motor roller shutter lifting mechanism

The most convenient way to open and close roller shutters is to opt for the electric motor option. A range of electric tubular motors and accessories are available from Advanced Shutter Industries for roller shutters which includes:

  • 240V mains powered tubular electric motors for roller shutters operated by hand-held radio remote control;
  • 240V mains powered tubular electric motors for roller shutters operated by a wall switch or keyed wall switch;
  • Group controls to simultaneously operate a number of electric roller shutters with a single switch;
  • Wind and rain sensors and timers to automatically open or close your electric roller shutters;
  • Back-up power for 240V mains powered electric roller shutters via Uninterruptible Power Supply (UPS), so in a power outage you can still open or close your roller shutters;
  • Free-wheeling safety clutch to avoid roller shutter damage if an obstruction is encountered while closing the roller shutter; and
  • Manual Override mechanisms as a safeguard to allow manual opening and closing of your roller shutters in case of a power outage.

Electric tubular motors for roller shutters are suitable for all roller shutter sizes all the way up to 250kg in weight.


Spring assist lifting mechanism

Roller shutters fitted with an assist spring as the lifting mechanism allow the roller shutter curtain to be physically raised and lowered by hand. The assist spring balances the weight of the roller shutter curtain and makes lifting and lowering the roller shutter easier and safer. Spring assist lifting mechanisms are suitable for roller shutters starting from 1.0 m wide. For commercial roller shutters wider than 2.7 m fitting a second assist spring is highly recommended to avoid axle torsion and ensure even lifting. In any case, we recommend use of an electric motor for roller shutters weighing more than 60 kg or wider than 3.0 m.

Colours


Curtain spacers

The spacers between each metal link on the Knightguard Security roller grille curtain are available in grey colour only.

  • Face fit or reveal fit;
  • Bulkhead, bracket or pelmet box fit (up to size limits);
  • Inwards or outwards facing roller shutter roll.


Grey (standard)


Guides, rails and links

All visible aluminium components on Knightguard Security Roller Grilles are available in clear anodised matt finish.

Optional powder coating of aluminium components to specified colour and anti graffiti coating are available as extras if required.

Clear Anodised (standard)

Others (optional)



Installation


Knightguard Security Roller Grilles are suitable for the following types of installation:

  • Face fit or reveal fit;
  • Bulkhead, bracket or pelmet box fit (up to size limits); and
  • Inwards or outwards facing roller shutter roll.

Technical Specifications


Curtain

Knightguard Security Roller Grille curtains consist of the following interconnected components:

  • 13 mm OD extruded aluminium tubes; and
  • a series of aluminium links; and
  • a series of pvc spacers.

The aluminium links are used to connect to aluminium tubes. The resulting curtain of the Knightguard Security Roller Grille forms a brick pattern with recurring openings of 200 mm wide x 45 mm high.

The interconnecting aluminium links which make up the Knightguard Security roller grille curtain offer very high strength and toughness.


Curtain Weight

4.7 kg / sqm

Add 1.5 kg / m for each mid rail or bottom rail.


Maximum Width

3200 mm

For width beyond roller shutter maximum specifications use multiple roller shutters within maximum width with fixed or removable mullions if appropriate.


Maximum Height

3000 mm


Side guides

Choice of roller shutter guides:

  • 76 mm x 32 mm clear anodised guides (suitable for face-fit or when optional pelmet box is fitted); or
  • 54 mm x 32 mm clear anodised guides available for use without pelmet box.

Bottom Rail

85 mm x 17 mm clear anodised Bottom Rail included as standard. Optional aluminium foot (64 mm deep) fitted under the bottom rail suitable for resting on counter tops is available if required.


Mid Rail

85 mm x 17 mm clear anodised Mid Rail is available as an optional extra to provide added strength or to house waist-height keylock.


Axle

70 mm diameter octagonal galvanized steel axle fitted with 130 mm diameter adaptor rings.


Roll Diameters for Bracket or Bulkhead Installation

  • Note: Dimensions are a guide only.
  • Incorporation of a midrail increases the roll diameter.
  • "A": Axle displacement suggested for distance of axle from wall or ceiling.
  • "D": Roll diameter.
  • "DLH": Daylight height of opeining.
"DLH" "A" "D"
1200 mm 130 mm 220 mm
1800 mm 145 mm 250 mm
2400 mm 155 mm 270 mm
3000 mm 165 mm 280 mm

Pelmet Box Fit Sizes

  • Note: Dimensions are a guide only.
  • Incorporation of a midrail increases the roll diameter.
  • "B": Pelmet box height and depth.
  • "OAH": Overall height of roller shutter from top of pelmet box to bottom of curtain travel (e.g. to ground or counter).
"OAH" "B"
1800 mm 250 mm
3000 mm 300 mm

Options


240V Electric Motors

Choice of 240V tubular electric motors for roller shutters:

  • Electric 240V motor; or
  • Electric 240V motor with manual override; or
  • Electric 240V motor with built-in radio remote receiver and paired radio remote control.

240V Electric Motor Accesories

A range of 240V electric motor accessories are available as optional extras:

  • Heavy duty key switch (in wall or on wall fitting) suitable for indoors and outdoors;
  • Electric 240V motor with built-in radio receiver and paired radio remote control;
  • Radio remote control plus keyring transmitter for standard 240V electric motors;
  • Group controls for operating multiple roller shutters;
  • Timers;
  • Wind and rain sensors;
  • Free-wheeling safety clutch that avoids damage to the roller shutter if an obstruction is encountered under the roller shutter while being lowered.

Counter-balance Assist Springs

A range of counter-balance assist springs and accessories:

  • Single Assist Spring;
  • Double Assist Spring;
  • Hook;
  • Keylock;
  • Extra Blank Keys.

Miscellaneous

A range of miscellaneous parts, accessories and services:

  • Removable 180° clear anodised mullion with lockable shoot & pad bolt;
  • Mid rail (85 mm x 17 mm) clear anodised for curtain;
  • Pelmet boxes of various sizes;
  • Fixed or removable panels matching the roller shutter curtain and guides. Ideal when in-fill panels are required;
  • Powder coating of all or some of the roller shutter parts;
  • Installation and delivery. Both can be arranged if required.

Due to continual product development the inclusions, features, colours and technical specifications of Advanced Shutter Industries products may change without notice.
